The LBA bit shall be set to one to specify the address is an LBA. DEV shall specify the selected device.
The native drive size is given in Drive/Head, Cyl Hi, Cyl Low and Sector num register as LBA value.
10.15 Read Sector(s) (20h or 21h)
This command reads from 1 to 256 sectors as specified in the Sector Count register. A sector count of 0 requests 256
sectors. The transfer begins at the sector specified in the Sector Number Register. When this command is issued
and after each sector of data (except the last one) has been read by the host, the Card sets BSY, puts the sector of
data in the buffer, sets DRQ, clears BSY, and generates an interrupt. The host then reads the 512 Bytes of data
from the buffer.
If an error occurs, the read terminates at the sector where the error occurred. The Command Block Registers
contain the cylinder, head, and sector number of the sector where the error occurred. The flawed data are
pending in the sector buffer. Table 72 defines the Read Sector command Byte sequence.
Table 72: Read sector(s)
Task File Register
7
6
5
4
3
2
1
0
COMMAND
20h or 21h
DRIVE/HEAD
1
LBA
1
D
Head (LBA 27-24)
CYLINDER HI
CYLINDER LOW
SECTOR NUM
SECTOR COUNT
FEATURES
Cylinder High (LBA23-16)
Cylinder Low (LBA15-8)
Sector Number (LBA7-0)
Sector Count
nu
10.16 Read Verify Sector(s) (40h or 41h)
This command is identical to the Read Sectors command, except that DRQ is never set and no data is transferred
to the host. When the command is accepted, the Card sets BSY. When the requested sectors have been verified,
the Card clears BSY and generates an interrupt.
If an error occurs, the verify terminates at the sector where the error occurs. The Command Block Registers contain
the cylinder, head and sector number of the sector where the error occurred. The Sector Count Register contains
the number of sectors not yet verified.
Table 73 defines the Read Verify Sector command Byte sequence.
Table 73: Read Verify Sector(s)
Task File Register
7
6
5
4
3
2
1
0
COMMAND
40h or 41h
DRIVE/HEAD
1
LBA
1
D
Head (LBA 27-24)
CYLINDER HI
CYLINDER LOW
SECTOR NUM
SECTOR COUNT
FEATURES
Cylinder High (LBA23-16)
Cylinder Low (LBA15-8)
Sector Number (LBA7-0)
Sector Count
nu
10.17 Recalibrate (1Xh)
This command is effectively a NOP command to the Card and is provided for compatibility purposes. Table 74
defines the Recalibrate command Byte sequence.
Table 74: Recalibrate
Task File Register
7
6
5
4
3
2
1
0
COMMAND
1Xh
DRIVE/HEAD
1
LBA
1
D
nu
CYLINDER HI
CYLINDER LOW
SECTOR NUM
SECTOR COUNT
FEATURES
nu
nu
nu
nu
nu
Swissbit AG
Industriestrasse 4
Swissbit reserves the right to change products or specifications without notice.
Revision: 1.51
CH-9552 Bronschhofen
Switzerland
www.swissbit.com
industrial@swissbit.com
C-300_data_sheet_CF-HxBK_Rev151.doc
Page 73 of 99
